Description

Drager 3359309 X-am 2500 Multi Gas Detector

The Dräger X-am 2500® was especially developed for use as personal protection. The 1 to 4 gas detector reliably detects combustible gases and vapours, as well as O2, CO, NO2, SO2 and H2S. Reliable and fully mature measuring technology, durable sensors and easy handling guarantee a high degree of safety with extremely low operating costs.

Benefits:

Durable electrochemical sensors

Fully developed, high performance Dräger sensors in an extra small format for CO, H2S, O2, SO2 and NO2 gases enable safe use in industry, mining and in refineries. The impressive hydrogen sulphide sensor has a high resolution, so it can reliably measure even very low workplace limits. The non-consumptive and lead-free sensor for oxygen is characterized by an especially long service life of more than 5 years. Our CO and H2S sensors also have this long service life expectation, so they contribute to especially low operating costs.

Maximum safety

The Dräger X-am 2500 has Ex approval for zone 0, so it is clearly designed for very high user safety in areas subject to explosion hazard. The functional design ensures that gas can enter from above and from the side – even if the instrument is inside a pocket or if the front gas entry is accidentally covered.

Diffusion or pump

For clearance measurements for tanks and shafts or when searching for leaks, an optional external pump with a hose up to 30 m long is the optimum solution. The pump starts automatically when the measuring instrument is inserted in the external pump. The switch from diffusion to pump operation can be handled quickly and easily without tools or screws. (optional Extra)

Reliable power supply

The Dräger X-am 2500 can operate with either alkaline batteries or with rechargeable NiMH batteries. This enables a reliable power supply for more than 12 hours, and with the high capacity battery pack more than 13 hours. Depending on the requirements, the batteries can be charged either in the workshop or in a vehicle. Operating time without Ex sensor is typically more than 250 hours.

Poison resistant ex sensor

The innovative, catalytic Ex sensor is im- pressive due to its high resistance to silicone and hydrogen sulphide. Together with the high degree of drift stability, this resistance enables an extraordinarily long service life of more than 4 years. Its sensitivity with regard to flammable gases and vapours is tested in accordance with the technical approval for measuring IEC/EN 60079-29-1 from methane to nonane. This approval also demonstrates the suitability of this instrument for primary explosion protection, e.g. for use in refineries and in the chemical industry.

Maintenance: fast, easy, inexpensive

From functional test to complete documentation, users have access to practical solutions that provide safety for implementation at any time. The Dräger Bump Test Station, which does not require a local power source, and the automatic Dräger X-dock testing and calibration station for comprehensive equipment management are ideal system additions that save time and effort. Together with the Dräger X-dock, the high quality Dräger sensors enable quick bump tests of 8 to 15 seconds1 with very low gas consumption. This significantly reduces your equipment operating costs.
With standard sensors: CH4, O2, CO, H2S

Ergonomic and robust

Thanks to its low weight and ergonomic design, the Dräger X-am 2500 offers a high degree of wearing comfort. The practical two button control panel and easy menu navigation allow the instrument to be used intuitively, despite its comprehensive functionality. The integrated protective rubber coating and sensors that are not sensitive to shock provide additional safety in case of impacts or vibrations. More-over, the Dräger X-am 2500 is not sensitive to electromagnetic radiation, e.g. from wireless devices. The Dräger X-am 2500 is water and dust resistant in accordance with protection class IP67, so it remains fully functional even if it falls into the water.

Data Sheet

Dräger X-am 2500 Kits

Dräger X-am 2500 Kits include the X-am 2500 complete with the NiMH rechargeable power pack and charger X-am 2500 Kit Single Gas EX 3360229

X-am 2500 Kit Dual gas Ex/O2 3360228

X-am 2500 Kit Three gas Ex/O2/H2S 3360226

X-am 2500 kit Three gas Ex/O2/CO 3360227

X-am 2500 kit Four gas Ex/O2/H2S/CO 3359309

Dräger X-am 2500 Instrument with exchangeable sensors but not expandable. Standard calibration of the Ex-sensor: Methane 0-100 %LEL. incl. default (Germany) alarm levels

X-am 2500 Ex, O2, CO, H2S-LC 8323918

X-am 2500 Ex, O2, CO 8323916

X-am 2500 Ex, O2, H2S-LC 8323914

X-am 2500 Ex, O2 8323912

X-am 2500 Ex 8323910

Accessories Power Packs and Charging Options,

X-am 2500 Alkaline power pack (without 2 AA batteries) 8318703

Alkaline batteries T4 (2pcs) for Alkaline power pack 8322240

Rechargeable NiMH power pack T4 8318704

Rechargeable NiMH pack extended life T4 (not for X-am 2000) 8322244

Charging module 8318639

Charging set basic: charging module with single charger 8320333

Power pack & charging set; NiMH power pack, charging module and single charger 8318785

Power Pack and Charging Set extended life battery 8322785

Single charger (max 2 charging modules) 8315635

Single charger (max 5 charging modules) 8316994

Power supply with connection (max 20 charging module) 8315805

Car charging connection 12v/24v 4530057

Vehicle charger mounting kit for 1 charging module 8318779

Additional strap for vehicle charger mounting kit 8318788

Dräger Replacement sensors for X-am 2500

Note: X-am 2500 Catex and XXS O2, CO, H2S sensors have a 3-year warranty XXS DrägerSensor O2 0 - 25 Vol-% 6810881

XXS DrägerSensor CO 0 - 2000ppm 6810882

XXS DrägerSensor H2S 0 - 200ppm 6810883

XXS DrägerSensor H2S/LC 0 - 100ppm - requires version 4 or higher firmware in instrument 6811525

XXS DrägerSensor NO2 0-50ppm. X-am 2500 only 6810884

XXS DrägerSensor SO2 0-100ppm. X-am 2500 only 6810885

Cat Ex 125 PR 0 - 100% LEL - requires version 4 or higher firmware in instrument 6812950

Products specifications

Attribute name	Attribute value
Gases Detected	Multi Gas O2, CO, H2S and LEL

Drager 3359309 X-am 2500 Multi Gas Detector

Gas Detected: 4 Gas H2S, CO, O2 and LEL
Type: Multi Gas Detector

Manufacturer: Drager

SKU: 3359309

£560.00 excl vat £672.00 inc vat
