Honeywell SPSTAXC1 Sensepoint 0-200ppm CO

Hazardous Area Gas Sensor with Junction Box
Manufacturer: Honeywell
SKU: SPSTAXC1
£421.20 inc vat £351.00 excl vat
decrease increase

Honeywell SPSTAXC1 Sensepoint 0-200ppm Carbon Monoxide Detector

Require Install, Commissioning, Calibration or Servicing?

Safety Gear Store are able to install, commission and service your fixed gas detection system. We offer a professional service from fully trained, certified and manufacturer approved engineers, we are also one of the only suppliers with engineers that carry spares in their vehicles to ensure a quick and efficient service that will enable you to continue using your facility.

For more information on what we offer please visit one of the below pages:

Fixed Gas Detection System Install and Commissioning

Fixed Gas Detection System Calibration and Servicing

Product advertised is SPSTAXC1 0-200ppm Carbon Monoxide, Sensepoint with pre-wired junction box [1x M20 (threaded), 1 X 3/4" NPT, 1 X 1/2" NPT]

Overview:

The Sensepoint range of flammable, toxic and Oxygen gas detectors offer users a high quality, low cost solution to their industrial gas monitoring needs. Installation in potentially explosive atmospheres is made by the use of a suitable Exd or Exe approved junction box. The industry standard outputs from Sensepoint are connected to either a choice of Honeywell Analytics’ controllers or 3rd party DCS / PLC systems. Both flammable and toxic versions are certified to the latest European ATEX safety and performance standards.


The flammable detector is available in either % LEL or PPM detection range versions and provides an industry standard mV bridge output. Typical life expectancy is greater than 5 years, after which the detector is simply replaced with a new one.

The toxic detectors are supplied pre calibrated for easy installation and provide an industry standard 2 wire 4-20mA loop output. User connections are Exd, while front end Intrinsic Safety (IS) design allows for easy exchange of the replaceable sensor while powered. IS design also removes the need for a sinter enabling very fast speed of response and detection of ‘sticky’ gases such as Chlorine and Ammonia.

Sensepoint has proven its suitability across a wide range of demanding applications by delivering high performance and reliability at an affordable cost.

Additional Features and Benefits:

Fit For Purpose:

  • Flammable, toxic and Oxygen versions available
  • High performance, low cost
  • Suitable for new and retrofit applications

Proven Sensor Technology:

  • Surecell™ electrochemical sensors
  • Poison resistant catalytic bead
  • Fast and reliable
  • Typical 2 to 5 years operational life

ATEX Certified:

  • Complies with the latest European standards
  • Hazardous area approval and performance
  • IP65 / 66 for use in harsh environments
  • Factory set operation
  • Simple to replace
  • Minimal training required

Range of Accessories:

  • Weatherproof cap
  • Flow adaptor
  • Duct mounting kit
  • Collecting cone

ATEX certified flammable, toxic and oxygen gas detectors that offer a high-quality, low-cost solution to monitoring hazardous areas.

Features and Benefits:
  • Proven SurecellTM electrochemical sensors
  • Fast and reliable
  • Minimal training required

Quick Specs:
  • Flammable, toxic and Oxygen versions available
  • Suitable for indoor or outdoor use
  • IP65 as standard

Data Sheet

Sensepoint with Junction Box



Part Number

Description



SPSTAXF1

0-100%LEL Methane, Sensepoint with pre-wired junction box [1x M20(threaded), 1 X 3/4" NPT, 1 X 1/2" NPT]

*1 *2

SPSTAXO1

0-25%v/v Oxygen, Sensepoint with pre-wired junction box [1x M20(threaded), 1 X 3/4" NPT, 1 X 1/2" NPT]

*1 *2

SPSTAXC1

0-200ppm Carbon Monoxide, Sensepoint with pre-wired junction box [1x M20(threaded), 1 X 3/4" NPT, 1 X 1/2" NPT]

*1

SPSTAXC2

0-500ppm Carbon Monoxide, Sensepoint with pre-wired junction box [1x M20(threaded), 1 X 3/4" NPT, 1 X 1/2" NPT]



SPSTAXH1

0-50ppm Hydrogen Sulphide, Sensepoint with pre-wired junction box [1x M20(threaded), 1 X 3/4" NPT, 1 X 1/2" NPT]

*1

SPSTAXH2

0-20ppm Hydrogen Sulphide, Sensepoint with pre-wired junction box [1x M20(threaded), 1 X 3/4" NPT, 1 X 1/2" NPT]



SPSTAXH3

0-100ppm Hydrogen Sulphide, Sensepoint with pre-wired junction box [1x M20(threaded), 1 X 3/4" NPT, 1 X 1/2" NPT]



SPSTAXG1

0-1,000ppm Hydrogen, Sensepoint with pre-wired junction box [1x M20(threaded), 1 X 3/4" NPT, 1 X 1/2" NPT]

*1

SPSTAXL1

0-5ppm Chlorine, Sensepoint with pre-wired junction box [1x M20(threaded), 1 X 3/4" NPT, 1 X 1/2" NPT]

*1

SPSTAXL2

0-15ppm Chlorine, Sensepoint with pre-wired junction box [1x M20(threaded), 1 X 3/4" NPT, 1 X 1/2" NPT]



SPSTAXS1

0-15ppm Sulphur Dioxide, Sensepoint with pre-wired junction box [1x M20(threaded), 1 X 3/4" NPT, 1 X 1/2" NPT]

*1

SPSTAXS2

0-50ppm Sulphur Dioxide, Sensepoint with pre-wired junction box [1x M20(threaded), 1 X 3/4" NPT, 1 X 1/2" NPT]



SPSTAXN1

0-10ppm Nitrogen Dioxide, Sensepoint with pre-wired junction box [1x M20(threaded), 1 X 3/4" NPT, 1 X 1/2" NPT]

*1 *2

SPSTAXA1

0-50ppm Ammonia, Sensepoint with pre-wired junction box [1x M20(threaded), 1 X 3/4" NPT, 1 X 1/2" NPT]

*1

SPSTAXA2

0-1000ppm Ammonia, Sensepoint with pre-wired junction box [1x M20(threaded), 1 X 3/4" NPT, 1 X 1/2" NPT]



*1 = Standard gas range to be used wherever possible. Parts generally available from stock.



*2 = Contact Honeywell Analytics for further information on alternate ranges.





Honeywell SPSTAXC1 Sensepoint 0-200ppm Carbon Monoxide Detector

Require Install, Commissioning, Calibration or Servicing?

Safety Gear Store are able to install, commission and service your fixed gas detection system. We offer a professional service from fully trained, certified and manufacturer approved engineers, we are also one of the only suppliers with engineers that carry spares in their vehicles to ensure a quick and efficient service that will enable you to continue using your facility.

For more information on what we offer please visit one of the below pages:

Fixed Gas Detection System Install and Commissioning

Fixed Gas Detection System Calibration and Servicing

Product advertised is SPSTAXC1 0-200ppm Carbon Monoxide, Sensepoint with pre-wired junction box [1x M20 (threaded), 1 X 3/4" NPT, 1 X 1/2" NPT]

Overview:

The Sensepoint range of flammable, toxic and Oxygen gas detectors offer users a high quality, low cost solution to their industrial gas monitoring needs. Installation in potentially explosive atmospheres is made by the use of a suitable Exd or Exe approved junction box. The industry standard outputs from Sensepoint are connected to either a choice of Honeywell Analytics’ controllers or 3rd party DCS / PLC systems. Both flammable and toxic versions are certified to the latest European ATEX safety and performance standards.


The flammable detector is available in either % LEL or PPM detection range versions and provides an industry standard mV bridge output. Typical life expectancy is greater than 5 years, after which the detector is simply replaced with a new one.

The toxic detectors are supplied pre calibrated for easy installation and provide an industry standard 2 wire 4-20mA loop output. User connections are Exd, while front end Intrinsic Safety (IS) design allows for easy exchange of the replaceable sensor while powered. IS design also removes the need for a sinter enabling very fast speed of response and detection of ‘sticky’ gases such as Chlorine and Ammonia.

Sensepoint has proven its suitability across a wide range of demanding applications by delivering high performance and reliability at an affordable cost.

Additional Features and Benefits:

Fit For Purpose:

  • Flammable, toxic and Oxygen versions available
  • High performance, low cost
  • Suitable for new and retrofit applications

Proven Sensor Technology:

  • Surecell™ electrochemical sensors
  • Poison resistant catalytic bead
  • Fast and reliable
  • Typical 2 to 5 years operational life

ATEX Certified:

  • Complies with the latest European standards
  • Hazardous area approval and performance
  • IP65 / 66 for use in harsh environments
  • Factory set operation
  • Simple to replace
  • Minimal training required

Range of Accessories:

  • Weatherproof cap
  • Flow adaptor
  • Duct mounting kit
  • Collecting cone

ATEX certified flammable, toxic and oxygen gas detectors that offer a high-quality, low-cost solution to monitoring hazardous areas.

Features and Benefits:
  • Proven SurecellTM electrochemical sensors
  • Fast and reliable
  • Minimal training required

Quick Specs:
  • Flammable, toxic and Oxygen versions available
  • Suitable for indoor or outdoor use
  • IP65 as standard

Data Sheet

Sensepoint with Junction Box



Part Number

Description



SPSTAXF1

0-100%LEL Methane, Sensepoint with pre-wired junction box [1x M20(threaded), 1 X 3/4" NPT, 1 X 1/2" NPT]

*1 *2

SPSTAXO1

0-25%v/v Oxygen, Sensepoint with pre-wired junction box [1x M20(threaded), 1 X 3/4" NPT, 1 X 1/2" NPT]

*1 *2

SPSTAXC1

0-200ppm Carbon Monoxide, Sensepoint with pre-wired junction box [1x M20(threaded), 1 X 3/4" NPT, 1 X 1/2" NPT]

*1

SPSTAXC2

0-500ppm Carbon Monoxide, Sensepoint with pre-wired junction box [1x M20(threaded), 1 X 3/4" NPT, 1 X 1/2" NPT]



SPSTAXH1

0-50ppm Hydrogen Sulphide, Sensepoint with pre-wired junction box [1x M20(threaded), 1 X 3/4" NPT, 1 X 1/2" NPT]

*1

SPSTAXH2

0-20ppm Hydrogen Sulphide, Sensepoint with pre-wired junction box [1x M20(threaded), 1 X 3/4" NPT, 1 X 1/2" NPT]



SPSTAXH3

0-100ppm Hydrogen Sulphide, Sensepoint with pre-wired junction box [1x M20(threaded), 1 X 3/4" NPT, 1 X 1/2" NPT]



SPSTAXG1

0-1,000ppm Hydrogen, Sensepoint with pre-wired junction box [1x M20(threaded), 1 X 3/4" NPT, 1 X 1/2" NPT]

*1

SPSTAXL1

0-5ppm Chlorine, Sensepoint with pre-wired junction box [1x M20(threaded), 1 X 3/4" NPT, 1 X 1/2" NPT]

*1

SPSTAXL2

0-15ppm Chlorine, Sensepoint with pre-wired junction box [1x M20(threaded), 1 X 3/4" NPT, 1 X 1/2" NPT]



SPSTAXS1

0-15ppm Sulphur Dioxide, Sensepoint with pre-wired junction box [1x M20(threaded), 1 X 3/4" NPT, 1 X 1/2" NPT]

*1

SPSTAXS2

0-50ppm Sulphur Dioxide, Sensepoint with pre-wired junction box [1x M20(threaded), 1 X 3/4" NPT, 1 X 1/2" NPT]



SPSTAXN1

0-10ppm Nitrogen Dioxide, Sensepoint with pre-wired junction box [1x M20(threaded), 1 X 3/4" NPT, 1 X 1/2" NPT]

*1 *2

SPSTAXA1

0-50ppm Ammonia, Sensepoint with pre-wired junction box [1x M20(threaded), 1 X 3/4" NPT, 1 X 1/2" NPT]

*1

SPSTAXA2

0-1000ppm Ammonia, Sensepoint with pre-wired junction box [1x M20(threaded), 1 X 3/4" NPT, 1 X 1/2" NPT]



*1 = Standard gas range to be used wherever possible. Parts generally available from stock.



*2 = Contact Honeywell Analytics for further information on alternate ranges.





Products specifications
SensepointToxic with pre-wired junction box
Gases DetectedCarbon Monoxide (CO)
*
*
*
Products specifications
SensepointToxic with pre-wired junction box
Gases DetectedCarbon Monoxide (CO)
