IGD TOC-750BAV Mutli Gas Detector - O2

Require Install, Commissioning, Calibration or Servicing?

Safety Gear Store are able to install, commission and service your fixed gas detection system. We offer a professional service from fully trained, certified and manufacturer approved engineers, we are also one of the only suppliers with engineers that carry spares in their vehicles to ensure a quick and efficient service that will enable you to continue using your facility.
For more information on what we offer please visit one of the below pages:

Fixed Gas Detection System Install and Commissioning

Fixed Gas Detection System Calibration and Servicing

This Gas Detector has a 0-25% Vol Detection Range and a 19.6% Nominal Alarm Point.
(Terminal Enclosure IP54 Cable Glands must be used)

Power Supply: 12 to 28V DC

Environmental: - 10 to +55 degrees Centigrade
                       - 0-95%RH Non-Condensing

Response Time: <30 Seconds

Expected Life: 5 years, no user replacable parts

Target Gas: 02

Service: This equipment must only be services by competent persons and checked periodically using traceable calibration gases. Do not test using lighter fuel or similar fuel hgases as this can give misleading results. In extreme cases this can result in sensor damage.

Standards Applied: EN50194-1:2009 Type A Equipment (Flammable Gas Detectors)

Data Sheet / Manual
