Reid Lifting Porta Gantry Rapide - Medium

2.0m - 4.0m Beam Length

250kg - 400kg Working Load Limit

Min 1454 - Max 2154mm Height to Lifting Eye

Manufacturer: Reid Lifting

SKU: PGRM20J

Model *
Trolley/Sheave Carrier *

£2,549.68 excl vat £3059.62 inc vat

Qty:

Description

Reid Lifting Porta Gantry Rapide - Medium

Reid's top quality and highly durable PORTAGANTRY is lightweight and extremely strong. This portable system can be manually assembled, using just four bolts and can safely lift to 5000kg, making it ideal for multiple applications.

Key Features

EN795:2012 Certified
ATEX Certified
Can support goods and personnel lifting;
- Goods WLL of up to 400kg
- Personnel WLL of up to 200kg
Suitable for up to 3 persons for fall protection applications
Integrated wheel design that folds with the frame for ease of transportation
Available in 3 height-adjustable versions [up to 2.9m to the lifting eye]
Can accommodate a range of beam lengths up to 4m
Anodised for increased corrosion resistance
Engineered designs and bespoke sections reduce weight, providing lightweight portability

Check out Reid's website for more specific Information on the Reid Porta Gantry Rapide

Operations Guide

Product Overview

Product also included in this range include:

PGRM20J	Porta-Gantry Rapide Medium. 2m beam. WLL400kg. Castor Foot
PGRM20K	Porta-Gantry Rapide Medium. 2m beam. WLL400kg. Articulated
PGRM23J	Porta-Gantry Rapide Medium. 2.3m beam. WLL400kg. Castor Foot
PGRM23K	Porta-Gantry Rapide Medium. 2.3m beam. WLL400kg. Articulated
PGRM40J	Porta-Gantry Rapide Medium. 4m beam. WLL250kg. Castor Foot
PGRM40K	Porta-Gantry Rapide Medium. 4m beam. WLL250kg. Articulated
PGRS20J	Porta-Gantry Rapide Small. 2m beam. WLL500kg. Castor Foot
PGRS20K	Porta-Gantry Rapide Small. 2m beam. WLL500kg. Articulated
PGRS23J	Porta-Gantry Rapide Small. 2.3m beam. WLL400kg. Castor Foot
PGRS23K	Porta-Gantry Rapide Small. 2.3m beam. WLL400kg. Articulated
PGRS40J	Porta-Gantry Rapide Small. 4m beam. WLL250kg. Castor Foot
PGRS40K	Porta-Gantry Rapide Small. 4m beam. WLL250kg. Articulated
PGRT20J	Porta-Gantry Rapide Tall. 2m beam. WLL250kg. Castor Foot
PGRT20K	Porta-Gantry Rapide Tall. 2m beam. WLL250kg. Articulated
PGRT23J	Porta-Gantry Rapide Tall. 2.3m beam. WLL250kg. Castor Foot
PGRT23K	Porta-Gantry Rapide Tall. 2.3m beam. WLL250kg. Articulated
PGRT30J	Porta-Gantry Rapide Tall with 3.0m beam WLL250kg Cast J
PGRT40J	Porta-Gantry Rapide Tall. 4m beam. WLL250kg. Castor Foot
PGRT40K	Porta-Gantry Rapide Tall. 4m beam. WLL250kg. Articulated
PGR1TM20J	Porta-Gantry Rapide Medium. 2m beam. WLL1000kg. Castor Foot
PGR1TM20K	Porta-Gantry Rapide Medium. 2m beam. WLL1000kg. Articulated
PGR1TM30J	Porta-Gantry Rapide Medium. 3m beam. WLL1000kg. Castor Foot
PGR1TM30K	Porta-Gantry Rapide Medium. 3m beam. WLL1000kg. Articulated
PGR1TM40J	Porta-Gantry Rapide Medium. 4m beam. WLL1000kg. Castor Foot
PGR1TM40K	Porta-Gantry Rapide Medium. 4m beam. WLL1000kg. Articulated
PGR1TS20J	Porta-Gantry Rapide Small. 2m beam. WLL1000kg. Castor Foot
PGR1TS20K	Porta-Gantry Rapide Small. 2m beam. WLL1000kg. Articulated
PGR1TS30J	Porta-Gantry Rapide Small. 3m beam. WLL1000kg. Castor Foot
PGR1TS30K	Porta-Gantry Rapide Small. 3m beam. WLL1000kg. Articulated
PGR1TS40J	Porta-Gantry Rapide Small. 4m beam. WLL1000kg. Castor Foot
PGR1TS40K	Porta-Gantry Rapide Small. 4m beam. WLL1000kg. Articulated
PGR1TT20J	Porta-Gantry Rapide Tall. 2m beam. WLL1000kg. Castor Foot
PGR1TT20K	Porta-Gantry Rapide Tall. 2m beam. WLL1000kg. Articulated
PGR1TT30J	Porta-Gantry Rapide Tall. 3m beam. WLL1000kg. Castor Foot
PGR1TT30K	Porta-Gantry Rapide Tall. 3m beam. WLL1000kg. Articulated
PGR1TT40J	Porta-Gantry Rapide Tall. 4m beam. WLL1000kg. Castor Foot
PGR1TT40K	Porta-Gantry Rapide Tall. 4m beam. WLL1000kg. Articulated
PGTTR00501	PGR Double Sheave Carrier - WLL500kg
PGTTR01001	PGR Double Sheave Carrier - WLL1000kg
PGTUR00501	PGR Single Sheave Carrier - WLL500kg
PGTUR01001	PGR Single Sheave Carrier - WLL1000kg
PGTXR00500	PGR Close Coupled Trolley - WLL500kg
PGTXR01000	PGR Close Coupled Trolley - WLL1000kg
PGTZR00250	PGR Masterlink Trolley - WLL250kg
PGTZR00400	PGR Masterlink Trolley - WLL400kg
PGTZR00500	PGR Masterlink Trolley - WLL500kg
PGTZR01000	PGR Masterlink Trolley - WLL1000kg
